Descrizione prodotto
Thanks to the AUTOMATIC TURRET ROTATION – AUTOMATIC CUT-OFF WITH AUTOMATIC RE-START – FINISHED JUMBO-ROLLS UNLOADING SYSTEM, it allows a great reduction of the downtime between cycles and a considerable production increase.
MAIN FEATURES:
- Working width: up to 1650 mm.
- Finished large-rolls max. diameter: 600 mm.
- Finished large-rolls inside diameter: 3” and 6”
- Min. slitting width: 20 mm.
- Slitting systems: by score-knives and/or shear-knives
- Mechanical speed: 250 m./min.
- Rewinding shafts: pneumatic differential type with spheres
- Automatic double-adhesive tab application for finished logs closing
- Automatic end cut-off with automatic re-start
FITTINGS:
- Finished large rolls automatic unloading
- Lateral support for the finished large-rolls
- Slitting system with knives automatic positioning
- Splicing table
- Manufacturing according to CE and FDA regulations
OTHERS FITTINGS AND DEVICES ACCORDING TO THE MATERIALS
AND THE NEEDS OF THE CUSTOMER
